LARGE BORE VALVES
offered by
INSTANT TOOLS INC.
Part No.
Heights
Total Length
Bend Degree
J670-03
1.63"

Straight
J650-03
1.08"
3.12"
80
J651-03
1.27"
4.69"
90
J652-03
1.08"
5.50"
86
J653-03
1.08"
2.50"
80
J654-03
1.08"
3.12"
60
J655-03
1.08"
3.12"
74
J656-03
2.62"
3.69"
90
J657-03
1.08"
4.00"
80
J658-03
1.08"
5.50"
80
J659-03
1.89"
3.50"
90
J660-03
1.89"
8.75"
90
J669-03
1.08"
2.50"
90
J4000-*
1.08"
CUSTOM
90
J661-03
1.08"
4.50"
82 / 8
J664-03
1.08"
8.75"
90 / 13
J667-03
1.08"
7.50"
90 / 11
J662-03
1.08"
14.00"
90 / 20 / 20
J663-03
1.08"
25.00"
90 / 8 / 8
J665-03
1.08"
32.00"
90 / 13 / 13
J666-03
1.08"
20.12"
84 / 6 / 31 / 31
J670-02
+
J650-02
+
SP-2
=
SP-2
=
J670-03
J650-03
J4000-*
Single-Bend and Double-Bend Tubeless Turret Valves
For planetary gear wheels. Fit 13/16" valve hole.
Part No.
Height
Total Length
Bend Degree
J691
0.50"
3.31"
18
J694
0.50"
3.50"
28
J690
0.50"
4.69"
28 / 28
J692
0.50"
4.69"
28 / 18
J693
0.50"
5.00"
45 / 45
J695
0.50"
4.12"
50 / 50
J696
0.50"
4.25"
42 / 42
Screw-On Repair Valves for Inner tubes
Straight or bent. Ready to use with SP-1000 Tube Spud..
Part No.
Height
Length
Bend Degree
J-1014
1.91"

Straight
J-1076A
4.16"

Straight
J-1076B
1.13"
3.25"
86
J-1076C
1.50"
2.88"
90
J-1076D
2.06"
2.31"
98
J-1076E
1.38"
3.00"
88
J-1078A
5.78"

Straight
J-1078B
1.38"
4.62"
82
J-1078C
1.13"
4.88"
90
J-1175A
5.28"

Straight
J-1175B
1.25"
4.25"
82
J-1175C
1.38"
4.13"
88
J-1179A
6.41"

Straight
J-1179B
1.38"
5.25"
88
J-1179C
1.13"
5.50"
86
